The model is a gantry type high rigid structure, which is precision manufactured by resin sand process. All castings are tempered twice and stress relieved, with good stability and no deformation.
10. Y and Z axes adopt high rigidity precision linear guide rail and C3 grade ball screw with high precision.
The drive system adopts AC servo drive, with high control precision, stable linkage of X, y and Z axes and small vibration of the machine tool.
A fourth axis or five axis turntable can be added.
| 名称及型号 | 单位 | ZT-545 | ZT-650 | ZT-860 |
| XYZ轴行程 | mm | 450*500*250 | 600*500*250 | 680*780 *330 |
| 龙门宽度 | mm | 575 | 760 | 760 |
| 工作台面积 | mm | 550*480 | 500*600 | 800*600 |
| 最大负重量 | kg | 300 | 350 | 500 |
| 主轴电机 | kw | 4.0 | 5.5 | 5.5 |
| 主轴转速 | rpm/min | 18000/24000 | 18000/24000 | 18000/24000 |
| 主轴规格 | ER20/ER25(标配）/BT30高速电主轴（选配） | |||
| 三轴最大移动速度 | mm/min | 12000 | 12000 | 12000 |
| 三轴最大加工速度 | mm/min | 6000 | 6000 | 6000 |
| 数控系统分辨率 | mm | 0.001 | 0.001 | 0.001 |
| 重复定位系统 | mm | JIS±0.003/300 | JIS±0.003/300 | JIS±0.003/300 |
| 定位精确度 | mm | JIS±0.003/300 | JIS±0.003/300 | JIS±0.003/300 |
| 主轴冷却系统 | 油冷（标配） | |||
| 润滑系统 | 自动润滑系统 | |||
| 切削油系统 | 双喷头（切削液，压缩空气） | |||
| 数控系统 | 台湾新代，宝元或西班牙发格 | |||
| 对刀仪 | 自动对刀仪 | |||
| 电源及总功率 |
三相交流电 380V31CW-7KW |
三相交流电 380V31CW-9KW |
三相交流电 380V31CW-11KW |
|
| kw | 0.75(x/y/z） | 0.85（x/y/z） | 1.0（x/y/z） | |
|
最大道具直径 （与主轴规格有关） |
Φ12 | Φ16 | Φ16 | |
| 机体重量 | T | 3 | 3.5 | 4.5 |
| 机床外形尺寸 | m | 1600*1600*2100 | 1800*1900*2200 | 2000*1980*2300 |
